PCS STEM CONNECTOR 336.4 - 600 KCMIL (25 PER BX)

Calculating price...
Ref: PCSL4
Mfr: PowerConnector Specialties, Inc
QUANTITY

About this item

PCSL4 Features

This is a one piece tinned aluminum straight connector, that is designed for street light use on both copper or aluminum conductors from #12 AWG to 1/0 AWG 1/C and pin type in-line fuse holders.

Features:

  • Material: Body: High tensile tin-plated aluminum alloy
  • Bolts: High tensile strength aluminum alloy
  • STEM: High tensile tin-plated Copper
  • Voltage: Up to 36 KV
  • Tools: 3/4” HEX (six point) deep well impact socket required. 18V battery impact tool recommended.



PCSL4 Specs

AWG/Kcmil

336.4 - 600 Kcmil

Bolts

3

Overall Body Length

1.77" (45 MM)

Sleeve Length

1.89" (48 MM)

Clamping Length

1.12" (28.5 MM)

Length of Pad

5.98" (152 MM)

Length

11.5" (292 MM)

Outside Diameter

0.55" (14 MM)
